Technical Specifications
Rated voltage | Rated bending resistance load | Structure height | Leakage distance | Lightning impulse withstand voltage | Power frequency withstand (wet) |
10 kv | 70 kN | 420 mm | 460 mm | 95 kv | 42 kv |
24 kv | 70 kN | 480 mm | 680 mm | 230 kv | 50 kv |
35 kv | 100 kN | 670 mm | 1280 mm | 230 kv | 95 kv |
66 kv | 100 kN | 940 mm | 1870 mm | 410 kv | 185 kv |
110 kv | 100 kN | 1305 mm | 3350 mm | 550 kv | 230 kv |
